Generali

Frequency coverage

Receive

118.0000 ~ 135.9950 MHz [4]
144.0000 ~ 148.0000 MHz [1][2]
144.0000 ~ 146.0000 MHz [3]
438.0000 ~ 450.0000 MHz [1]
430.0000 ~ 440.0000 MHz [2][3]

Transmit

144.0000 ~ 148.0000 MHz [1][2]
144.0000 ~ 146.0000 MHz [3]
438.0000 ~ 450.0000 MHz [1]
430.0000 ~ 440.0000 MHz [2][3]

Mode

AM [4] / FM

Tuning step

5 / 10 / 12.5 / 15 / 20 / 25 kHz
1 / 10 MHz (rapid freq. excursions)

Ricevitore

Sensitivity

144 MHz

<0.16 uV (12dB SINAD)
<0.25 uV (12dB SINAD) [5]

430 MHz

<0.16 uV (12dB SINAD)
<0.25 uV (12dB SINAD) [5]

Selectivity

FM

>12 kHz (-6dB)
<28 kHz (-60dB)

RF attenuator

Yes [6]

Frequency stability

±10ppm max

IF (Intermediate Frequency)

1°

45.050 MHz (for 144 MHz)
58.525 MHz (for 430/440 MHz)

2°

455 kHz

Squelch sensitivity

<0.1 uV

Trasmettitore

Output power

144 MHz

5 (Low) / 10 (Mid) / 50 (High) W

430 MHz

5 (Low) / 10 (Mid) / 35 (High) W

Spurious emission

<-60 dBc

Maximum deviation (FM)

±5.0 kHz

Microphone

600Ω

Funzioni

Memory

70 regular memories
2 call channels (VHF + UHF)
2 scan ranges (VHF + UHF)
6 programmable memory (PM) for all settings

Display

sub-kHz frequency resolution
7-segments signal meter bar

Selective calling

1750 Hz tone
DTMF dialing
CTCSS tones [7]

Antenna

2 x SO239 50Ω [1]
SO239 50Ω [2]
N 50Ω [3]

Power supply

13.8 VDC (nominal, ±15%)

Power consumption

<1.2A RX (no signal)
<11.5A TX (VHF, at 50W RF power)
<10A TX (UHF, at 35W RF power)

Audio power

2W on 8Ω

Audio output

2 x Jack 3.5 mm (external speakers)
