GENERAL

Type:

Amateur HF transceiver

Frequency range:

TX: 10-160 m + WARC
RX: 0.1-30 MHz

Tuning steps:

10 / 50 / 100 Hz, 1 / 5 / 25 / 500 KHz

Frequency stability:

±100 Hz @ -10 to +60°C (14 to 140°F)

Mode:

AM / FM / SSB / CW / RTTY

Channels / memory management:

32 regular
2 scan edge
RAM storage with lithium battery backup

Repeater shift / offset:

No dedicated. Use VFO A/B split

Power supply:

Mains: 100-120 VAC (USA) or 200-240 VAC (Europe & Australia)
(3-pin IEC C14 connector)

Current drain / power consumption:

RX: Max 80 VA
TX: Max 650 VA

Antenna impedance / connector:

50 ohm (16.7-150 ohm with ATU on) / SO-239

Dimensions (W*H*D):

424*150*390 mm (16.69*5.91*15.35")

Weight:

17.5 Kg (38.58 lb)

Other features:

NB. PBT. Transverter jack. VOX. CI-V computer control. Auto-ATU.
Electronic keyer with full QSK.
